Welcome to the Toyota Prius Battery (TPB) site. Here you'll find links and information pertaining to the Prius battery. This includes how it works, what it costs and modifications you can make to it.
Newest Prius Article
- Toyota Prius Plug-In Hybrid Provides 112MPGe
-
If you haven't seen the official commercial yet, feel free to check it out on our main page. As of the 2011 Frankfurt Motor Show, Toyota has officially expanded the Prius into a family. These include the larger Prius minivan, the original Prius, and the electric plug-in Prius.
more >>
Prius Battery Specifications:
There are two batteries found in a Prius. The first is a lead-acid (Pb-A) 12v accessory battery which is commonly found in most vehicles on the road. The second is the main hybrid driving battery, which is specific to hybrid electric vehicles (HEV) and electric vehicles (EV). We at TPB are primarily concerned with the latter.
Starting in 2004 to the current models, the standard Prius battery is a Panasonic Metal Case Prismatic Module. Prior to 2004 and as early as 2000 the battery used was a Panasonic Plastic Case Prismatic Module. The first generation was sold only in Japan. Of the 70,000 sold a small but significant number of vehicles had problems with the battery pack. Furthermore, the battery pack was so large it took up the entire space between the trunk and the cabin. This led to changes in the Generation II models whose stacks were significantly smaller and far more reliable.
| 97 Prius (Generation I) Japan Only |
00 Prius (Generation II) |
04 Prius (Generation III) |
2010 Prius (Generation IV) |
|
|---|---|---|---|---|
| Form Factor | Cylindrical | Prismatic | Prismatic | Prismatic |
| Cells (Modules) | 240 (40) | 228 (38) | 168 (28) | 168 (28) |
| Nominal Voltage | 288.0 V | 273.6 V | 201.6 V | 201.6 V |
| Nominal Capacity | 6.0Ah | 6.5Ah | 6.5Ah | 6.5Ah |
| Specific Power | 800 W/kg | 1000 W/kg | 1300 W/kg | 1310 W/kg |
| Specific Energy | 40 Wh/kg | 46 Wh/kg | 46 Wh/kg | 44 Wh/kg |
| Module Weight | 1090g | 1050g | 1045g | 1040g |
| Module Dimensions | 35(oc)x384(L) | 19.6x106x275 | 19.6x106x285 | 19.6x106x285 |
Videos
2010 Toyota Prius
Prius Mods:
Many Toyota Prius users are thrilled by the efficiency the hybrid has to offer, but want just a little more out of their car. As a result, many owners hack their car in order to achieve a variety of results. These include increasing mileage and running on electric power only (called "EV" mode).
While many hacks can be performed by the average user, you should understand the risks involved in the process before modifying your Prius. Often undertaking such modifications will void your car's warranty (most importantly the battery warranty). It is also possible to damage your car if hacked incorrectly.
More information can be found below:
